Instrumentation
;)
- Microprocessor based for fast and accurate measurements.
- Special viewing angle designed of waterproof housing IP 57 rated. It floats on water.
- Large LCD display pH or ORP or Conductivity or TDS or Salinity or DO and Temperature Simultaneously.
- Simple to calibrate by one keyboard and automatic temperature compensation(ATC), Manual Salinity(MSC) and Altitude(MAC) Compensation.
- Multi-functions with Data-hold, Max/Min and shows PTS after calibration. Degree ℃/℉ are switchable.
- Low battery and consumption indicator. Auto power shut off after 10 minutes of non use.
- Easy to replace electrode module, and the type of electrode would be recognized automatically and shown in display during insertion.
Specifications
| 7200 | |||||||
| 7011 | 7021 | ||||||
| pH | mV | Temp. | Cond. | TDS | Salt | Temp. | |
| Range | -2 ~ 16.00 | -1000 ~ 1000 | 0 ~ 90 ℃ | 0 ~ 2000 μS 2.00~20.00 mS |
0 ~ 1300 ppm 1.30 ~ 13.00 ppt |
0 ~1000 ppm 1.00 ~ 12.00 ppt |
0 ~ 90 ℃ |
| Accuracy | ± 0.01 + 1digit | ±2 + 1digit | ± 0.2 + 1digit | ± 2% FS ( Cond., TDS, Salt) | ± 0.2 ℃ + 1digit | ||
| Resolution | 0.01 | 1 | 0.1 ℃ | 1 μS/0.01 mS | 1 ppm/0.01 ppt | 1 ppm/0.01 ppt | 0.1 ℃ |
| ATC | 0 ~ 90 ℃ | 0 ~ 50 ℃ | |||||
| Calibration | pH 4.00, 7.00, 10.01 | 0, 1413 μS, 12.88 mS | |||||
| Power | DC1.5V x 4 battery size:AAA/UM-4 | ||||||
| 7031 | |||||
| DO | O2 | Temp | |||
| Range | 0~20.00mg/L | 0~200% | 0~90.0℃ | ||
| Accuracy | ±0.2 + 1digit | ± 2% FS | ±0.2+1 digit | ||
| Resolution | 0.01 | 0.1 | 0.1 | ||
| ATC | 0~50 ℃ | ||||
| MSC | 0~50 ppt | ||||
| MAC | 0-20000 ft | ||||
| Calibration | 100% in air | ||||
| Power | DC1.5V x 4 battery size:AAA/UM-4 | ||||
| Dimensions | Meter: 195 x 40 x 36 mm, Kits: 230 x 205 x 50 mm | ||||
| Weight | Meter: 135g(with battery), Kits: 780g | ||||
Accessories for complete kit:
| 7011 | 7021 | 7031 | 7200 | |
| Sensor | pH | Cond. Cell | DO | pH + Cond. Cell |
| Standard Solution |
pH 4 & 7 | 1413 μS | None | pH 4 & 7 1413 μS |
| Soaking Solution |
Yes | None | Yes | Yes |
| Battery 1.5 × 4, Lanyard connection, Carring case, Instruction manual | ||||
| Optional: OPR Electrode | ||||
